Automated gravimetric feeding lines and reinforced belt conveyors for stable continuous flow of dry bulk minerals. High-resolution load cell hoppers ensure precise mass balance in every batch.
Our engineers will review your gravimetric line and recommend load cell upgrades to improve mass balance accuracy.
Schedule AuditGet detailed datasheets for the GF-200 feeder, HBC-500 conveyor, and LCH-1000 hopper series with wiring diagrams.
Download PDFStraightforward answers about gravimetric feeding, belt conveyors, and load cell hoppers for dry bulk mineral handling.
The GF-200 maintains a mass flow accuracy of ±0.5% of setpoint under steady-state conditions. This is achieved through dual load cells and a PID controller that adjusts the auger speed in real time. Accuracy may vary slightly with material density changes, but the system auto-compensates within two to three seconds.
Yes. The HBC-500 is built with a chevron-pattern belt and vulcanized splices to resist wear from sand, gravel, and crushed minerals. Impact idlers at loading zones reduce belt damage, and the sealed gearmotor prevents dust ingress. For extremely abrasive feeds, we recommend an optional rubber liner at the loading point.
Calibration is done via the digital weight transmitter using either the front-panel buttons or a remote Modbus command. You can perform a zero calibration with an empty hopper and a span calibration using certified test weights. The transmitter stores up to five calibration sets for different materials.
Our gravimetric feeders and load cell hoppers support Modbus RTU, Modbus TCP, and Ethernet/IP. The belt conveyor can be integrated via discrete I/O or optional Profibus. All systems can be linked to a central PLC for coordinated line control.
Routine maintenance includes weekly inspection of the auger for material buildup, monthly load cell zero checks, and quarterly cleaning of the hopper interior. The gearbox should be lubricated every 500 operating hours. A full maintenance guide is included with each unit.
Yes. We offer on-site commissioning for all systems, including calibration, integration with existing controls, and operator training. Remote support via video call is also available for troubleshooting and minor adjustments. Contact our service team for scheduling.
Combines the GF-200 auger feeder with a 1000 kg load cell hopper for closed-loop mass flow control. Includes PID tuning parameters for cement and mineral powders, Modbus RTU wiring diagram, and remote calibration procedure. Suitable for lines requiring ±0.5% accuracy at 2–15 t/h.
Heavy-duty HBC-500 conveyor with integrated belt scale and digital integrator. Provides real-time throughput data for process monitoring and mass balance reconciliation. Includes impact idler set, chevron belt, and sealed gearmotor. Handles inclines up to 20° for sand, gravel, and crushed minerals.
Two-tonne load cell hopper with three-point suspension and Ethernet/IP weight transmitter. Bundled with a programmable batch controller for multi-ingredient blending. Supports up to 8 recipes with automatic discharge and refill logic. Ideal for bagging lines and continuous blending processes.
End-to-end solution from feeding to transport to weighing. Includes the GF-200 gravimetric feeder, HBC-500 belt conveyor, and LCH-1000 hopper with all interconnecting chutes and control wiring. Commissioning checklist and Modbus configuration file provided. Designed for new installations or retrofitting existing dry bulk lines.
Each package includes a technical datasheet, wiring schematic, and remote support for first-time setup. Contact us for custom configurations with different capacities or material types.
Why Larderandco
Volumetric feeders drift with bulk density changes. Our GF-200 series uses dual load cells and closed-loop auger speed control to maintain setpoint mass flow regardless of material compaction or moisture variation. The result is repeatable dosing for cement, minerals, and chemical blends.
Standard belt conveyors fail under sand, gravel, and crushed minerals — belt tracking drifts, idlers seize, and gearboxes ingest dust. The HBC-500 uses chevron-pattern vulcanized belts, sealed gearmotors, and impact idlers at every loading zone. It handles inclines up to 20° without material rollback and integrates with upstream feeders for continuous operation.
Many weighing systems lose accuracy due to mechanical binding or electrical noise. Our LCH-1000 series uses three-point hermetically sealed load cells with digital weight transmitters outputting via Ethernet/IP or 4-20 mA. Capacities from 500 kg to 5000 kg with 0.1% full-scale accuracy — no drift, no re-zeroing every shift.
We have supplied gravimetric feeding lines to cement plants, mineral blending facilities, and chemical processors across India. Our systems run 24/7 with remote calibration and Modbus data logging. When mass balance is critical, engineers choose Larderandco for repeatable results and minimal downtime.
